Product Details:
|
| Model: | EP-95A | Name: | Conductive TPU |
|---|---|---|---|
| Color: | Transparent Or Customized | Hardness: | 96A-99A |
| Grade: | Injection | Advantage: | Shoe Materials, Leather, Other Plastic Parts, Phone Cases, Sports Equipment Accessories |
| Feature: | Environmentally Friendly | Transparency: | 1.5-2.0MM |
| Highlight: | Modified Conductive TPU,Conductive TPU Granules,Polyurethane raw recycled plastic |
||
Conductive TPU for Electronic Component Parts with High Heat Resistance and Impact Resistance
Specification
| Item | Value |
| Place of Origin | Guangdong,China |
| Brand Name | DingZhi |
| Model Number | EP-95A |
| Product name | Conductive TPU |
| Color | Transparent/Customized |
| Application | Toys cables wires |
| Hardness | 70A/75A/80A/85A/90A/95A/98A TPU Polyurethane Granules |
| Type | Virgin & Off grade |
| Grade | Injection |
| Advantage | Oil-resistant water-resistant mold-resistant impact-resistant |
| Feature | Environmentally Friendly |
| Advantage |
1. Competitive price, high quality, on-time delivery, free sample 2. Environment friendly 3. High Heat Resistance, High impact resistance 4. Without any impurity 5. Can be reinforced with the glass fiber/toughness/flame retardant/UV stabilizer |
| Characteristic |
1. wear resistance. TPU plastic raw material has excellent wear resistance, more than five times the wear resistance of natural rubber. 6. High-temperature resistance and oxidation resistance. TPU has good antioxidant capacity; The temperature resistance can reach 120℃. |
| Application | Shoe purpose: shoe soles, shoe decoration, snow boot…etc. Wheel purpose: skate wheel, castor wheel, load wheel…etc. Industrial parts purpose: O-ring, oil seal, gasket…etc. Mobile purpose: mobile protection case, mobile phone accessories…etc. |
| Package | 25KG per carton |
| Payment terms | TT, LC, Paypal. |
| Delivery time | Within 7-10 days |
| MOQ | 1 Kg and Free Sample |
| Capacity per day | 25 tons |
Product features:
Fast forming and easy processing
Application area:
Shoe materials, leather, other plastic parts, phone cases, sports equipment accessories
DATA SHEET :
| Performance items | Test Method | Test Unite | Test Results |
| Hardness | ISO R 868 | Shore | 96A-99A |
| Proportion | ASTM D-792 | g/cm³ | 1.21 |
| Melting index value | ISO 1133 | g/10min | 22.3/2.16KG |
| DIN friction loss | DIN-53516 | mm³ | 88 |
| Tear strength | ASTM D-624 | kN/m | 191.8 |
| Tensile strength | ASTM D-412 | ㎏/c㎡ | 451.7 |
| Total elongation at break | ASTM D-412 | % | 451 |
| 100% modulus | ASTM D-412 | ㎏/c㎡ | 150.2 |
| Anti UV/anti yellowing | Sunlight 300W/50 degrees/24hours | NA | |
| Transparency | Visual inspection of step test pieces | 1.5-2.0MM | |
