Product Details:
|
Low Temperature Resistance: | Good | Weather Resistance: | Excellent |
---|---|---|---|
Oil Resistance: | Good | Tear Resistance: | Excellent |
Water Resistance: | Excellent | Hardness: | Shore A 60-98 |
Abrasion Resistance: | Excellent | High Temperature Resistance: | Excellent |
Highlight: | Polyurethane plastic recycling pellets,Custom plastic recycling pellets,Polyurethane resin plastic pellets |
Tpu Raw Material Granules Shore A 85 Hardness For Extrusion Molding Non Flammable
Specification
Item | Value |
Place of Origin | Guangdong,China |
Brand Name | DingZhi |
Model Number | DM-80A |
Product name | Polyether-Based TPU Granule |
Color | Transparent/Customized |
Application | Livestock Ear Tags |
Hardness | 80A |
Type | Virgin & Off grade |
Grade | Injection |
Advantage | Oil-resistant water-resistant mold-resistant impact-resistant |
Feature | Environmentally Friendly |
Advantage |
1. Competitive price, high quality, on-time delivery, free sample 2. Environment friendly 3. High Heat Resistance, High impact resistance 4. Without any impurity 5. Can be reinforced with the glass fiber/toughness/flame retardant/UV stabilizer |
Characteristic |
1. wear resistance. TPU plastic raw material has excellent wear resistance, more than five times the wear resistance of natural rubber. 6. High-temperature resistance and oxidation resistance. TPU has good antioxidant capacity; The temperature resistance can reach 120℃. |
Application | Shoe purpose: shoe soles, shoe decoration, snow boot…etc. Wheel purpose: skate wheel, castor wheel, load wheel…etc. Industrial parts purpose: O-ring, oil seal, gasket…etc. Mobile purpose: mobile protection case, mobile phone accessories…etc. |
Package | 25KG per bag |
Payment terms | TT,Western union. |
Delivery time | Within 7-10 days |
MOQ | 1 Kg and Free Sample |
Capacity per day | 25 tons |
PRODUCT PARAMETERS
TPU Material is widely used in film product because its excellent property. Polyether based-TPU is with good excellent hydrolytic resistance, bacteria resistance, aging resistance. perfect Physical properties.meet your needs.
Performance items | Test Method | Test Unite | Test Results |
Hardness | ISO R 868 | Shore | 80-82A |
Proportion | ASTM D-792 | g/cm³ | 1.205 |
Melting index value | ISO 1133 | g/10min | 18.3/2.16KG |
DIN friction loss | DIN-53516 | mm³ | 81.5 |
Tear strength | ASTM D-624 | kN/m | 110 |
Tensile strength | ASTM D-412 | ㎏/c㎡ | 351 |
Total elongation at break | ASTM D-412 | % | 485 |
100% modulus | ASTM D-412 | ㎏/c㎡ | 76.5 |
Anti UV/anti yellowing | Sunlight 300W/50 degrees/24hours | ||
Transparency | Visual inspection of step test pieces | 2.0-3.0MM |
Production Process:
Drying requirements: Please dry at 80-90 ℃ for 3-4 hours;
Injection temperature: 170-185 degrees for the first section, 175-190 degrees for the second section, and 180-200 degrees for the third section
Pressure: 75-110 Pa
THE MAIN CHARACTERISTICS OF TPU
PRODUCT APPLICATION:
TPU has many applications including automotive instrument panels, caster wheels, power tools, sporting goods, medical devices, drive belts, footwear, inflatable rafts, and a variety of extruded film, sheet, and profile applications. TPU is also a popular material found in outer cases of mobile electronic devices, such as mobile phones. It is also used to make keyboard protectors for laptops. TPU is well known for its applications in performance films, wire and cable jacketing, hose, and tube, in adhesive and textile coating applications, and as an impact modifier of other polymers. TPU pellets are used as most recent cushioning technology, known as Boost. Several thousands of TPU pellets are bound together to create a comfortable sole for the shoe.
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
